Transformer Capacity & Loss Tester

Transformer Capacity & Loss Tester
Product name:Transformer Capacity & Loss Tester


l  This is a high precision integrated test instrument, not only for checking out transformer capacity, but also for testing transformer performance such as no-load current, no-load loss, short-circuit voltage, short-circuit loss, impedance voltage, etc.

l  It has high quality chargeable battery, one charge can last for 100 times test continuously.

l  Internal digital synthesis standard sine wave (not contravariant AC output), can provide 3-phase precision AC test power, after being amplified.

l  When measuring capacity and short-circuit loss, there don’t need auxiliary equipments such as 3-phase test power, regulator and current-upgrading equipment.

l  High accuracy rate of capacity test result, 100%!

l  Big test range: max. voltage can be 750V!

l  Automatically carry out wave distortion rectifying, temperature rectifying and voltage rectifying (no-load test under non-rated voltage), current rectifying (short-circuit under non-rated current).

l  Large-size LCD displaying, menu operation

l  Test data can be printed out at any time

Main parameters

1)      Input characteristics:

Active section: voltage measuring range 0~10V; current measuring range: 0~10A

Passive section: voltage measuring range 0~750V; current measuring range: 0~100A, automatic shifting measuring range.

2)      Accuracy:

Voltage, current, frequency: +/-0.2%

Power: +/-0.5 (Cos Φ >0.1), +/-1.0% (0.02)

3)      Ambient temperature: 10~ +40

4)      Working power: AC 160V~400V

5)      Insulation:

Insulation resistance of input terminal to meter cover: 100MΩ

Power-frequency withstand voltage test of input terminal to meter cover: 2kV, last for 1 minute

6)      Dimension: 400 x 320 x 180mm

7)      Weight: 4kg
